Technical Specifications of 3094R-561JS
| Datasheet |  3094R-561JS datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | API Delevan Inc. |
|---|
| Series | 3094R |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | - |
|---|
| Material - Core | Iron |
|---|
| Inductance | 560nH |
|---|
| Tolerance | ±5% |
|---|
| Current Rating | 510mA |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 190 mOhm Max |
|---|
| Q @ Freq | 70 @ 25MHz |
|---|
| Frequency - Self Resonant | 170MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Frequency - Test | 25MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 2-SMD |
|---|
| Size / Dimension | 0.163" L x 0.133" W (4.14mm x 3.38mm) |
|---|
| Height - Seated (Max) | 0.140" (3.56mm) |
|---|
We can supply API Delevan Inc. part# 3094R-561JS. Use the request quote form to request 3094R-561JS pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 3094R-561JS. The price and lead time for 3094R-561JS depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 3094R-561JS. We look forward to doing business with you.
