Technical Specifications of VLM13580T-R82M-D1
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | TDK Corporation |
|---|
| Series | VLM |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 820nH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 12.6A |
|---|
| Current - Saturation | 36A |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 2 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | AEC-Q200 |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.531" L x 0.480" W (13.50mm x 12.20mm) |
|---|
| Height - Seated (Max) | 0.327" (8.30mm) |
|---|
We can supply TDK Corporation part# VLM13580T-R82M-D1. Use the request quote form to request VLM13580T-R82M-D1 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number VLM13580T-R82M-D1. The price and lead time for VLM13580T-R82M-D1 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# VLM13580T-R82M-D1. We look forward to doing business with you.
