Technical Specifications of PA4343.501NLT
| Datasheet |  PA4343.501NLT datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Pulse Electronics Corporation |
|---|
| Series | PA4343NLT |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Molded |
|---|
| Material - Core | - |
|---|
| Inductance | 500nH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 40A |
|---|
| Current - Saturation | 60A |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 1.25 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | AEC-Q200 |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.551" L x 0.504" W (14.00mm x 12.80mm) |
|---|
| Height - Seated (Max) | 0.256" (6.50mm) |
|---|
We can supply Pulse Electronics Corporation part# PA4343.501NLT. Use the request quote form to request PA4343.501NLT pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PA4343.501NLT. The price and lead time for PA4343.501NLT depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PA4343.501NLT. We look forward to doing business with you.
