Technical Specifications of LD2-101-R
| Datasheet |  LD2-101-R datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Eaton |
|---|
| Series | LD |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 100μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 1.53A |
|---|
| Current - Saturation | 1.15A |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 430 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.307" L x 0.276" W (7.80mm x 7.00mm) |
|---|
| Height - Seated (Max) | 0.197" (5.00mm) |
|---|
We can supply Eaton part# LD2-101-R. Use the request quote form to request LD2-101-R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number LD2-101-R. The price and lead time for LD2-101-R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# LD2-101-R. We look forward to doing business with you.
