Technical Specifications of C-59U
| Datasheet |  C-59U datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Triad Magnetics |
|---|
| Series | - |
|---|
| Packaging | Bulk |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | - |
|---|
| Inductance | 10mH |
|---|
| Tolerance | -20%, +50% |
|---|
| Current Rating | 12.5A |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 100 mOhm |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | - |
|---|
| Frequency - Test | - |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 4.125" L x 3.000" W (104.77mm x 76.20mm) |
|---|
| Height - Seated (Max) | 3.500" (88.90mm) |
|---|
We can supply Triad Magnetics part# C-59U. Use the request quote form to request C-59U pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number C-59U. The price and lead time for C-59U depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# C-59U. We look forward to doing business with you.
