Technical Specifications of HM11-22005LF
| Datasheet |  HM11-22005LF datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | TT Electronics/BI Magnetics |
|---|
| Series | HM11 |
|---|
| Packaging | Bulk |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | - |
|---|
| Inductance | 16.2μH |
|---|
| Tolerance | ±25% |
|---|
| Current Rating | 5.5A |
|---|
| Current - Saturation | 22A |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 30.6 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 105°C |
|---|
| Frequency - Test | 10kHz |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Radial |
|---|
| Size / Dimension | 0.490" Dia (12.40mm) |
|---|
| Height - Seated (Max) | 1.063" (27.00mm) |
|---|
We can supply TT Electronics/BI Magnetics part# HM11-22005LF. Use the request quote form to request HM11-22005LF pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number HM11-22005LF. The price and lead time for HM11-22005LF depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# HM11-22005LF. We look forward to doing business with you.
