Technical Specifications of HM71S-1305221LFTR
| Datasheet |  HM71S-1305221LFTR datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | TT Electronics/BI Magnetics |
|---|
| Series | HM71S |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | - |
|---|
| Inductance | 220μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 500mA |
|---|
| Current - Saturation | 500mA |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 2 Ohm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.510" L x 0.370" W (12.95mm x 9.40mm) |
|---|
| Height - Seated (Max) | 0.200" (5.08mm) |
|---|
We can supply TT Electronics/BI Magnetics part# HM71S-1305221LFTR. Use the request quote form to request HM71S-1305221LFTR pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number HM71S-1305221LFTR. The price and lead time for HM71S-1305221LFTR depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# HM71S-1305221LFTR. We look forward to doing business with you.
