Technical Specifications of TPL802727-193H
| Datasheet |  TPL802727-193H datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | TDK Corporation |
|---|
| Series | TPL |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | - |
|---|
| Material - Core | - |
|---|
| Inductance | 18.52mH |
|---|
| Tolerance | ±3% |
|---|
| Current Rating | - |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 240 Ohm Max |
|---|
| Q @ Freq | 40 @ 125kHz |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | AEC-Q200 |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Frequency - Test | 125kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.309" L x 0.106" W (7.85mm x 2.70mm) |
|---|
| Height - Seated (Max) | 0.114" (2.90mm) |
|---|
We can supply TDK Corporation part# TPL802727-193H. Use the request quote form to request TPL802727-193H pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number TPL802727-193H. The price and lead time for TPL802727-193H depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# TPL802727-193H. We look forward to doing business with you.
