LTC2258CUJ-14#PBF
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | LTC2258CUJ-14#PBF |
|---|---|
| Manufacturer | Linear Technology |
| Description | 14 Bit Analog to Digital Converter 1 Input 1 Pipelined 40-QFN (6x6) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| LTC2258CUJ-14#PBF Price |  |
Technical Specifications of LTC2258CUJ-14#PBF
| Datasheet |  LTC2258CUJ-14#PBF datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Analog to Digital Converters (ADC) |
| Manufacturer | Linear Technology |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Number of Bits | 14 |
| Sampling Rate (Per Second) | 65M |
| Number of Inputs | 1 |
| Input Type | Differential |
| Data Interface | LVDS - Parallel, Parallel |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | Pipelined |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 1.7 V ~ 1.9 V |
| Voltage - Supply, Digital | 1.7 V ~ 1.9 V |
| Features | - |
| Operating Temperature | 0°C ~ 70°C |
| Package / Case | 40-WFQFN Exposed Pad |
| Supplier Device Package | 40-QFN (6x6) |
