MCP3424-E/ST
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MCP3424-E/ST |
|---|---|
| Manufacturer | Microchip Technology |
| Description | 18 Bit Analog to Digital Converter 4 Input 1 Sigma-Delta 14-TSSOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MCP3424-E/ST Price |  |
Technical Specifications of MCP3424-E/ST
| Datasheet |  MCP3424-E/ST datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Analog to Digital Converters (ADC) |
| Manufacturer | Microchip Technology |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Number of Bits | 18 |
| Sampling Rate (Per Second) | 3.75 |
| Number of Inputs | 4 |
| Input Type | Differential |
| Data Interface | I2C |
| Configuration | MUX-PGA-ADC |
| Ratio - S/H:ADC | - |
| Number of A/D Converters | 1 |
| Architecture | Sigma-Delta |
| Reference Type | Internal |
| Voltage - Supply, Analog | 2.7 V ~ 5.5 V |
| Voltage - Supply, Digital | 2.7 V ~ 5.5 V |
| Features | PGA, Selectable Address |
| Operating Temperature | -40°C ~ 125°C |
| Package / Case | 14-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 14-TSSOP |
