ADS8330IRSATG4
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | ADS8330IRSATG4 |
|---|---|
| Manufacturer | Texas Instruments |
| Description | 16 Bit Analog to Digital Converter 2 Input 1 SAR 16-QFN (4x4) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| ADS8330IRSATG4 Price |  |
Technical Specifications of ADS8330IRSATG4
| Datasheet |  ADS8330IRSATG4 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Analog to Digital Converters (ADC) |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Number of Bits | 16 |
| Sampling Rate (Per Second) | 1M |
| Number of Inputs | 2 |
| Input Type | Differential, Single Ended |
| Data Interface | SPI |
| Configuration | S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 1.65 V ~ 5.5 V |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 16-VQFN Exposed Pad |
| Supplier Device Package | 16-QFN (4x4) |
