TLV2543CDB
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TLV2543CDB |
|---|---|
| Manufacturer | Texas Instruments |
| Description | 12 Bit Analog to Digital Converter 11 Input 1 SAR 20-SSOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| TLV2543CDB Price |  |
Technical Specifications of TLV2543CDB
| Datasheet |  TLV2543CDB datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Analog to Digital Converters (ADC) |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Number of Bits | 12 |
| Sampling Rate (Per Second) | 66k |
| Number of Inputs | 11 |
| Input Type | Single Ended |
| Data Interface | SPI |
| Configuration | MUX-S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External |
| Voltage - Supply, Analog | 3 V ~ 3.6 V |
| Voltage - Supply, Digital | 3 V ~ 3.6 V |
| Features | - |
| Operating Temperature | 0°C ~ 70°C |
| Package / Case | 20-SSOP (0.209", 5.30mm Width) |
| Supplier Device Package | 20-SSOP |
