AD7682BCPZRL7
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | AD7682BCPZRL7 |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Description | 16 Bit Analog to Digital Converter 4 Input 1 SAR 20-LFCSP-WQ (4x4) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| AD7682BCPZRL7 Price |  |
Technical Specifications of AD7682BCPZRL7
| Datasheet |  AD7682BCPZRL7 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Analog to Digital Converters (ADC) |
| Manufacturer | Analog Devices Inc. |
| Series | PulSAR? |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Number of Bits | 16 |
| Sampling Rate (Per Second) | 250k |
| Number of Inputs | 4 |
| Input Type | Differential, Pseudo-Differential, Single Ended |
| Data Interface | SPI, DSP |
| Configuration | MUX-S/H-ADC |
| Ratio - S/H:ADC | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 2.3 V ~ 5.5 V |
| Voltage - Supply, Digital | 2.3 V ~ 5.5 V |
| Features | Temperature Sensor |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 20-WFQFN Exposed Pad, CSP |
| Supplier Device Package | 20-LFCSP-WQ (4x4) |
