DS1869-100+
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | DS1869-100+ |
|---|---|
| Manufacturer | Maxim Integrated |
| Description | Digital Potentiometer 100k Ohm 1 Circuit 64 Taps Up/Down (UP, DN) Interface 8-PDIP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| DS1869-100+ Price |  |
Technical Specifications of DS1869-100+
| Datasheet |  DS1869-100+ datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Digital Potentiometers |
| Manufacturer | Maxim Integrated |
| Series | Dallastat? |
| Packaging | Tube |
| Part Status | Obsolete |
| Taper | Linear |
| Configuration | Rheostat |
| Number of Circuits | 1 |
| Number of Taps | 64 |
| Resistance (Ohms) | 100k |
| Interface | Up/Down (UP, DN) |
| Memory Type | Non-Volatile |
| Voltage - Supply | ±2.7 V ~ 8 V |
| Features | - |
| Tolerance | ±20% |
| Temperature Coefficient (Typ) | 750 ppm/°C |
| Resistance - Wiper (Ohms) (Typ) | 400 |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | 8-PDIP |
