DAC0800LCM
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | DAC0800LCM |
|---|---|
| Manufacturer | Texas Instruments |
| Description | 8 Bit Digital to Analog Converter 1 16-SOIC |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| DAC0800LCM Price |  |
Technical Specifications of DAC0800LCM
| Datasheet |  DAC0800LCM datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Digital to Analog Converters (DAC) |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Number of Bits | 8 |
| Number of D/A Converters | 1 |
| Settling Time | 150μs |
| Output Type | Current - Unbuffered |
| Differential Output | Yes |
| Data Interface | Parallel |
| Reference Type | External |
| Voltage - Supply, Analog | ±4.5 V ~ 18 V |
| Voltage - Supply, Digital | - |
| INL/DNL (LSB) | - |
| Architecture | Multiplying DAC |
| Operating Temperature | 0°C ~ 70°C |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 16-SOIC |
