AD7837BR
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | AD7837BR |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Description | 12 Bit Digital to Analog Converter 2 24-SOIC W |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| AD7837BR Price |  |
Technical Specifications of AD7837BR
| Datasheet |  AD7837BR datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Digital to Analog Converters (DAC) |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tube |
| Part Status | Obsolete |
| Number of Bits | 12 |
| Number of D/A Converters | 2 |
| Settling Time | 5μs |
| Output Type | Voltage - Buffered |
| Differential Output | Yes |
| Data Interface | Parallel |
| Reference Type | External |
| Voltage - Supply, Analog | ±14.25 V ~ 15.75 V |
| Voltage - Supply, Digital | - |
| INL/DNL (LSB) | ±0.5 (Max), ±1 (Max) |
| Architecture | R-2R |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 24-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 24-SOIC W |
