ADDAC80-CBI-V
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | ADDAC80-CBI-V |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Description | 12 Bit Digital to Analog Converter 1 24-CDIP Side Brazed |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| ADDAC80-CBI-V Price |  |
Technical Specifications of ADDAC80-CBI-V
| Datasheet |  ADDAC80-CBI-V datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Digital to Analog Converters (DAC) |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tube |
| Part Status | Obsolete |
| Number of Bits | 12 |
| Number of D/A Converters | 1 |
| Settling Time | 4μs |
| Output Type | Voltage - Buffered |
| Differential Output | No |
| Data Interface | Parallel |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | ±11.4 V ~ 16.5 V |
| Voltage - Supply, Digital | 4.5 V ~ 16 V |
| INL/DNL (LSB) | ±0.25, ±0.75 (Max) |
| Architecture | R-2R |
| Operating Temperature | -25°C ~ 85°C |
| Package / Case | 24-CDIP (0.600", 15.24mm) |
| Supplier Device Package | 24-CDIP Side Brazed |
