AD5338BRMZ
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | AD5338BRMZ |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Description | 10 Bit Digital to Analog Converter 2 8-MSOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| AD5338BRMZ Price |  |
Technical Specifications of AD5338BRMZ
| Datasheet |  AD5338BRMZ datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Digital to Analog Converters (DAC) |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Number of Bits | 10 |
| Number of D/A Converters | 2 |
| Settling Time | 9μs |
| Output Type | Voltage - Buffered |
| Differential Output | No |
| Data Interface | I2C |
| Reference Type | External |
| Voltage - Supply, Analog | 2.5 V ~ 5.5 V |
| Voltage - Supply, Digital | 2.5 V ~ 5.5 V |
| INL/DNL (LSB) | ±0.5, ±0.05 |
| Architecture | String DAC |
| Operating Temperature | -40°C ~ 105°C |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
| Supplier Device Package | 8-MSOP |
