MAX521BCAG+
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MAX521BCAG+ |
|---|---|
| Manufacturer | Maxim Integrated |
| Description | 8 Bit Digital to Analog Converter 8 24-SSOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MAX521BCAG+ Price |  |
Technical Specifications of MAX521BCAG+
| Datasheet |  MAX521BCAG+ datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Data Acquisition - Digital to Analog Converters (DAC) |
| Manufacturer | Maxim Integrated |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Number of Bits | 8 |
| Number of D/A Converters | 8 |
| Settling Time | 6μs (Typ) |
| Output Type | Voltage - Buffered |
| Differential Output | No |
| Data Interface | I2C |
| Reference Type | External |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 5V |
| INL/DNL (LSB) | ±2 (Max), ±1 (Max) |
| Architecture | R-2R |
| Operating Temperature | 0°C ~ 70°C |
| Package / Case | 24-SSOP (0.209", 5.30mm Width) |
| Supplier Device Package | 24-SSOP |
