AD7503JQ
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | AD7503JQ |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Description | 1 Circuit IC Switch 8:1 300 Ohm 16-CDIP |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| AD7503JQ Price |  |
Technical Specifications of AD7503JQ
| Datasheet |  AD7503JQ datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Analog Devices Inc. |
| Series | - |
| Packaging | Tube |
| Part Status | Obsolete |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | 8:1 |
| Number of Circuits | 1 |
| On-State Resistance (Max) | 300 Ohm |
| Channel-to-Channel Matching (ΔRon) | 12 Ohm |
| Voltage - Supply, Single (V+) | - |
| Voltage - Supply, Dual (V±) | ±15V |
| Switch Time (Ton, Toff) (Max) | 800ns, 800ns (Typ) |
| -3db Bandwidth | - |
| Charge Injection | - |
| Channel Capacitance (CS(off), CD(off)) | 5pF, 30pF |
| Current - Leakage (IS(off)) (Max) | - |
| Crosstalk | - |
| Operating Temperature | - |
| Package / Case | 16-CDIP (0.300", 7.62mm) |
| Supplier Device Package | 16-CDIP |
