MAX306EWI+T
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MAX306EWI+T |
|---|---|
| Manufacturer | Maxim Integrated |
| Description | 1 Circuit IC Switch 16:1 100 Ohm 28-SOIC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MAX306EWI+T Price |  |
Technical Specifications of MAX306EWI+T
| Datasheet |  MAX306EWI+T datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Maxim Integrated |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | 16:1 |
| Number of Circuits | 1 |
| On-State Resistance (Max) | 100 Ohm |
| Channel-to-Channel Matching (ΔRon) | 1.5 Ohm |
| Voltage - Supply, Single (V+) | 5 V ~ 30 V |
| Voltage - Supply, Dual (V±) | ±4.5 V ~ 20 V |
| Switch Time (Ton, Toff) (Max) | 200ns, 150ns |
| -3db Bandwidth | - |
| Charge Injection | 2pC |
| Channel Capacitance (CS(off), CD(off)) | 8pF, 130pF |
| Current - Leakage (IS(off)) (Max) | 500pA |
| Crosstalk | -92dB @ 100kHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 28-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 28-SOIC |
