MAX4600EWE
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MAX4600EWE |
|---|---|
| Manufacturer | Maxim Integrated |
| Description | 2 Circuit IC Switch 1:1 1.25 Ohm 16-SO |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| MAX4600EWE Price |  |
Technical Specifications of MAX4600EWE
| Datasheet |  MAX4600EWE datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Maxim Integrated |
| Series | - |
| Packaging | Tube |
| Part Status | Obsolete |
| Switch Circuit | SPST - NO/NC |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Number of Circuits | 2 |
| On-State Resistance (Max) | 1.25 Ohm |
| Channel-to-Channel Matching (ΔRon) | 50 mOhm |
| Voltage - Supply, Single (V+) | 4.5 V ~ 36 V |
| Voltage - Supply, Dual (V±) | ±4.5 V ~ 20 V |
| Switch Time (Ton, Toff) (Max) | 160ns, 210ns |
| -3db Bandwidth | - |
| Charge Injection | -60pC |
| Channel Capacitance (CS(off), CD(off)) | 115pF, 115pF |
| Current - Leakage (IS(off)) (Max) | 500pA |
| Crosstalk | -65dB @ 1MHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 16-SO |
