ALD4212PCL
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | ALD4212PCL |
|---|---|
| Manufacturer | Advanced Linear Devices Inc. |
| Description | 4 Circuit IC Switch 1:1 135 Ohm 16-PDIP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| ALD4212PCL Price |  |
Technical Specifications of ALD4212PCL
| Datasheet |  ALD4212PCL datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Advanced Linear Devices Inc. |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Switch Circuit | SPST - NO |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Number of Circuits | 4 |
| On-State Resistance (Max) | 135 Ohm |
| Channel-to-Channel Matching (ΔRon) | 2.7 Ohm |
| Voltage - Supply, Single (V+) | 3 V ~ 12 V |
| Voltage - Supply, Dual (V±) | ±1.5 V ~ 6 V |
| Switch Time (Ton, Toff) (Max) | 130ns, 130ns |
| -3db Bandwidth | - |
| Charge Injection | 0.2pC |
| Channel Capacitance (CS(off), CD(off)) | 3pF, 3pF |
| Current - Leakage (IS(off)) (Max) | 100pA |
| Crosstalk | -90dB @ 100kHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 16-DIP (0.300", 7.62mm) |
| Supplier Device Package | 16-PDIP |
