MAX4742EUA+
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MAX4742EUA+ |
|---|---|
| Manufacturer | Maxim Integrated |
| Description | 2 Circuit IC Switch 1:1 800 mOhm 8-uMAX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MAX4742EUA+ Price |  |
Technical Specifications of MAX4742EUA+
| Datasheet |  MAX4742EUA+ datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Maxim Integrated |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Switch Circuit | SPST - NC |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Number of Circuits | 2 |
| On-State Resistance (Max) | 800 mOhm |
| Channel-to-Channel Matching (ΔRon) | 50 mOhm |
| Voltage - Supply, Single (V+) | 1.6 V ~ 3.6 V |
| Voltage - Supply, Dual (V±) | - |
| Switch Time (Ton, Toff) (Max) | 24ns, 16ns |
| -3db Bandwidth | 100MHz |
| Charge Injection | 28pC |
| Channel Capacitance (CS(off), CD(off)) | 32pF, 32pF |
| Current - Leakage (IS(off)) (Max) | 1nA |
| Crosstalk | -110dB @ 1MHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
| Supplier Device Package | 8-uMAX |
