FSA2457UMX
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | FSA2457UMX |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Description | 2 Circuit IC Switch 2:2 7 Ohm 16-UMLP (1.8x2.6) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| FSA2457UMX Price |  |
Technical Specifications of FSA2457UMX
| Datasheet |  FSA2457UMX datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Fairchild Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Switch Circuit | DPDT |
| Multiplexer/Demultiplexer Circuit | 2:2 |
| Number of Circuits | 2 |
| On-State Resistance (Max) | 7 Ohm |
| Channel-to-Channel Matching (ΔRon) | - |
| Voltage - Supply, Single (V+) | 2.7 V ~ 3.6 V |
| Voltage - Supply, Dual (V±) | - |
| Switch Time (Ton, Toff) (Max) | 7ns, 4ns |
| -3db Bandwidth | 160MHz |
| Charge Injection | - |
| Channel Capacitance (CS(off), CD(off)) | 6pF |
| Current - Leakage (IS(off)) (Max) | 1μA |
| Crosstalk | -54dB @ 25MHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 16-UFQFN |
| Supplier Device Package | 16-UMLP (1.8x2.6) |
