TS12A44513DR
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TS12A44513DR |
|---|---|
| Manufacturer | Texas Instruments |
| Description | 4 Circuit IC Switch 1:1 10 Ohm 14-SOIC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| TS12A44513DR Price |  |
Technical Specifications of TS12A44513DR
| Datasheet |  TS12A44513DR datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Digi-Reel? |
| Part Status | Active |
| Switch Circuit | SPST - NO/NC |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Number of Circuits | 4 |
| On-State Resistance (Max) | 10 Ohm |
| Channel-to-Channel Matching (ΔRon) | 2.5 Ohm (Max) |
| Voltage - Supply, Single (V+) | 2.7 V ~ 12 V |
| Voltage - Supply, Dual (V±) | - |
| Switch Time (Ton, Toff) (Max) | 75ns, 45ns |
| -3db Bandwidth | 530MHz |
| Charge Injection | -10.5pC |
| Channel Capacitance (CS(off), CD(off)) | 8pF, 8pF |
| Current - Leakage (IS(off)) (Max) | 1nA |
| Crosstalk | - |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 14-SOIC |
