MAX4519CEE
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MAX4519CEE |
|---|---|
| Manufacturer | Maxim Integrated |
| Description | 2 Circuit IC Switch 2:1 100 Ohm 16-QSOP |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| MAX4519CEE Price |  |
Technical Specifications of MAX4519CEE
| Datasheet |  MAX4519CEE datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Maxim Integrated |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Switch Circuit | DPST - NO |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Number of Circuits | 2 |
| On-State Resistance (Max) | 100 Ohm |
| Channel-to-Channel Matching (ΔRon) | 4 Ohm (Max) |
| Voltage - Supply, Single (V+) | 2 V ~ 15 V |
| Voltage - Supply, Dual (V±) | ±2.7 V ~ 8 V |
| Switch Time (Ton, Toff) (Max) | 150ns, 150ns |
| -3db Bandwidth | - |
| Charge Injection | 5pC (Max) |
| Channel Capacitance (CS(off), CD(off)) | 5pF, 10pF |
| Current - Leakage (IS(off)) (Max) | 100pA |
| Crosstalk | -92dB @ 100kHz |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Package / Case | 16-SSOP (0.154", 3.90mm Width) |
| Supplier Device Package | 16-QSOP |
