MAX317EPA
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MAX317EPA |
|---|---|
| Manufacturer | Maxim Integrated |
| Description | 1 Circuit IC Switch 1:1 35 Ohm 8-PDIP |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| MAX317EPA Price |  |
Technical Specifications of MAX317EPA
| Datasheet |  MAX317EPA datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Maxim Integrated |
| Series | - |
| Packaging | Tube |
| Part Status | Obsolete |
| Switch Circuit | SPST - NC |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Number of Circuits | 1 |
| On-State Resistance (Max) | 35 Ohm |
| Channel-to-Channel Matching (ΔRon) | 2 Ohm (Max) |
| Voltage - Supply, Single (V+) | 10 V ~ 30 V |
| Voltage - Supply, Dual (V±) | ±4.5 V ~ 20 V |
| Switch Time (Ton, Toff) (Max) | 175ns, 145ns |
| -3db Bandwidth | - |
| Charge Injection | 3pC |
| Channel Capacitance (CS(off), CD(off)) | 8pF, 8pF |
| Current - Leakage (IS(off)) (Max) | 250pA |
| Crosstalk | -85dB @ 1MHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Supplier Device Package | 8-PDIP |
