PI5A3157CEX
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | PI5A3157CEX |
|---|---|
| Manufacturer | Pericom |
| Description | 1 Circuit IC Switch 2:1 13 Ohm SC-70-6 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| PI5A3157CEX Price |  |
Technical Specifications of PI5A3157CEX
| Datasheet |  PI5A3157CEX datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Pericom |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Switch Circuit | SPDT |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Number of Circuits | 1 |
| On-State Resistance (Max) | 13 Ohm |
| Channel-to-Channel Matching (ΔRon) | 150 mOhm |
| Voltage - Supply, Single (V+) | 1.65 V ~ 5.5 V |
| Voltage - Supply, Dual (V±) | - |
| Switch Time (Ton, Toff) (Max) | 5.2ns, 3.5ns |
| -3db Bandwidth | 250MHz |
| Charge Injection | 7pC |
| Channel Capacitance (CS(off), CD(off)) | 2.3pF |
| Current - Leakage (IS(off)) (Max) | 100nA |
| Crosstalk | -54dB @ 10MHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Supplier Device Package | SC-70-6 |
