MAX335CWG
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MAX335CWG |
|---|---|
| Manufacturer | Maxim Integrated |
| Description | 8 Circuit IC Switch 1:1 150 Ohm 24-SOIC |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| MAX335CWG Price |  |
Technical Specifications of MAX335CWG
| Datasheet |  MAX335CWG datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Maxim Integrated |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Switch Circuit | SPST - NO |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Number of Circuits | 8 |
| On-State Resistance (Max) | 150 Ohm |
| Channel-to-Channel Matching (ΔRon) | - |
| Voltage - Supply, Single (V+) | - |
| Voltage - Supply, Dual (V±) | ±4.5 V ~ 20 V |
| Switch Time (Ton, Toff) (Max) | 400ns, 400ns |
| -3db Bandwidth | - |
| Charge Injection | - |
| Channel Capacitance (CS(off), CD(off)) | 2pF, 2pF |
| Current - Leakage (IS(off)) (Max) | 1nA |
| Crosstalk | -100dB @ 100kHz |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Package / Case | 24-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 24-SOIC |
