MM74HC4052N
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MM74HC4052N |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Description | 2 Circuit IC Switch 4:1 100 Ohm 16-PDIP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MM74HC4052N Price |  |
Technical Specifications of MM74HC4052N
| Category | Integrated Circuits (ICs) |
|---|---|
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Fairchild Semiconductor |
| Series | - |
| Packaging | Tube |
| Part Status | Obsolete |
| Switch Circuit | SP4T |
| Multiplexer/Demultiplexer Circuit | 4:1 |
| Number of Circuits | 2 |
| On-State Resistance (Max) | 100 Ohm |
| Channel-to-Channel Matching (ΔRon) | 15 Ohm |
| Voltage - Supply, Single (V+) | 2 V ~ 6 V |
| Voltage - Supply, Dual (V±) | ±2 V ~ 6 V |
| Switch Time (Ton, Toff) (Max) | 41ns, 32ns |
| -3db Bandwidth | 35MHz |
| Charge Injection | - |
| Channel Capacitance (CS(off), CD(off)) | 5pF, 45pF |
| Current - Leakage (IS(off)) (Max) | 100nA |
| Crosstalk | -50dB @ 1MHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 16-DIP (0.300", 7.62mm) |
| Supplier Device Package | 16-PDIP |
