NX3V1G384GM,115
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | NX3V1G384GM,115 |
|---|---|
| Manufacturer | NXP Semiconductors |
| Description | 1 Circuit IC Switch 1:1 450 mOhm 6-XSON, SOT886 (1.45x1) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| NX3V1G384GM,115 Price |  |
Technical Specifications of NX3V1G384GM,115
| Datasheet |  NX3V1G384GM,115 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | NXP Semiconductors |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Switch Circuit | SPST - NC |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Number of Circuits | 1 |
| On-State Resistance (Max) | 450 mOhm |
| Channel-to-Channel Matching (ΔRon) | - |
| Voltage - Supply, Single (V+) | 1.4 V ~ 4.3 V |
| Voltage - Supply, Dual (V±) | - |
| Switch Time (Ton, Toff) (Max) | 26ns, 10ns |
| -3db Bandwidth | 25MHz |
| Charge Injection | 12pC |
| Channel Capacitance (CS(off), CD(off)) | 70pF |
| Current - Leakage (IS(off)) (Max) | 10nA |
| Crosstalk | - |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Package / Case | 6-XFDFN |
| Supplier Device Package | 6-XSON, SOT886 (1.45x1) |
