74HC4066
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 74HC4066 |
|---|---|
| Manufacturer | Fairchild/Micross Components |
| Description | 4 Circuit IC Switch 1:1 95 Ohm Die |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 74HC4066 Price |  |
Technical Specifications of 74HC4066
| Category | Integrated Circuits (ICs) |
|---|---|
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Manufacturer | Fairchild/Micross Components |
| Series | - |
| Packaging | Tray |
| Part Status | Active |
| Switch Circuit | SPST - NO |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Number of Circuits | 4 |
| On-State Resistance (Max) | 95 Ohm |
| Channel-to-Channel Matching (ΔRon) | 3 Ohm |
| Voltage - Supply, Single (V+) | 2 V ~ 10 V |
| Voltage - Supply, Dual (V±) | - |
| Switch Time (Ton, Toff) (Max) | 30ns, 20ns |
| -3db Bandwidth | 200MHz |
| Charge Injection | - |
| Channel Capacitance (CS(off), CD(off)) | 3.5pF |
| Current - Leakage (IS(off)) (Max) | 1μA |
| Crosstalk | -60dB @ 1MHz |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Package / Case | Die |
| Supplier Device Package | Die |
