TS5V330PW
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TS5V330PW |
|---|---|
| Manufacturer | Texas Instruments |
| Description | IC VIDEO SWIT QUAD SPDT 16TSSOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| TS5V330PW Price |  |
Technical Specifications of TS5V330PW
| Datasheet |  TS5V330PW datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Interface - Analog Switches - Special Purpose |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Applications | Video |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Switch Circuit | SPDT |
| Number of Channels | 4 |
| On-State Resistance (Max) | 10 Ohm |
| Voltage - Supply, Single (V+) | 4 V ~ 5.5 V |
| Voltage - Supply, Dual (V±) | - |
| -3db Bandwidth | 300MHz (Min) |
| Features | Bi-Directional, RGB |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 16-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 16-TSSOP |
