ACPL-C780-000E
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | ACPL-C780-000E |
|---|---|
| Manufacturer | Broadcom Limited |
| Description | Isolation Amplifier 1 Circuit Differential 8-SSO |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| ACPL-C780-000E Price |  |
Technical Specifications of ACPL-C780-000E
| Datasheet |  ACPL-C780-000E datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps |
| Manufacturer | Broadcom Limited |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Amplifier Type | Isolation |
| Number of Circuits | 1 |
| Output Type | Differential |
| Slew Rate | - |
| Gain Bandwidth Product | - |
| -3db Bandwidth | 100kHz |
| Current - Input Bias | - |
| Voltage - Input Offset | 300μV |
| Current - Supply | 11mA |
| Current - Output / Channel | 18.6mA |
| Voltage - Supply, Single/Dual (±) | 4.5 V ~ 5.5 V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.268", 6.81mm Width) |
| Supplier Device Package | 8-SSO |
