EL5420CS-T13
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | EL5420CS-T13 |
|---|---|
| Manufacturer | Intersil |
| Description | Voltage Feedback Amplifier 4 Circuit Rail-to-Rail 14-SOIC |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| EL5420CS-T13 Price |  |
Technical Specifications of EL5420CS-T13
| Datasheet |  EL5420CS-T13 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps |
| Manufacturer | Intersil |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Amplifier Type | Voltage Feedback |
| Number of Circuits | 4 |
| Output Type | Rail-to-Rail |
| Slew Rate | 10 V/μs |
| Gain Bandwidth Product | 8MHz |
| -3db Bandwidth | 12MHz |
| Current - Input Bias | 2nA |
| Voltage - Input Offset | 2mV |
| Current - Supply | 500μA |
| Current - Output / Channel | 30mA |
| Voltage - Supply, Single/Dual (±) | 4.5 V ~ 16.5 V, ±2.25 V ~ 8.25 V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 14-SOIC |
