N74F51D,602
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | N74F51D,602 |
|---|---|
| Manufacturer | NXP Semiconductors |
| Description | AND/OR/INVERT Gate Configurable 2 Circuit 10 Input (3, 3, 2, 2) Input 14-SO |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| N74F51D,602 Price |  |
Technical Specifications of N74F51D,602
| Datasheet |  N74F51D,602 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Logic - Gates and Inverters - Multi-Function, Configurable |
| Manufacturer | NXP Semiconductors |
| Series | 74F |
| Packaging | Tube |
| Part Status | Obsolete |
| Logic Type | AND/OR/INVERT Gate |
| Number of Circuits | 2 |
| Number of Inputs | 10 Input (3, 3, 2, 2) |
| Schmitt Trigger Input | No |
| Output Type | Differential |
| Current - Output High, Low | 1mA, 20mA |
| Voltage - Supply | 4.5 V ~ 5.5 V |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 14-SO |
