74AUP1G0832GW,125
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 74AUP1G0832GW,125 |
|---|---|
| Manufacturer | NXP Semiconductors |
| Description | AND/OR Gate Configurable 1 Circuit 3 Input (2, 1) Input 6-TSSOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 74AUP1G0832GW,125 Price |  |
Technical Specifications of 74AUP1G0832GW,125
| Datasheet |  74AUP1G0832GW,125 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | Logic - Gates and Inverters - Multi-Function, Configurable |
| Manufacturer | NXP Semiconductors |
| Series | 74AUP |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Logic Type | AND/OR Gate |
| Number of Circuits | 1 |
| Number of Inputs | 3 Input (2, 1) |
| Schmitt Trigger Input | No |
| Output Type | Single-Ended |
| Current - Output High, Low | 4mA, 4mA |
| Voltage - Supply | 0.8 V ~ 3.6 V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Supplier Device Package | 6-TSSOP |
