Technical Specifications of 74AHC04PW-Q100J
| Datasheet |  74AHC04PW-Q100J datasheet |
|---|
| Category | Integrated Circuits (ICs) |
|---|
| Family | Logic - Gates and Inverters |
|---|
| Manufacturer | NXP Semiconductors |
|---|
| Series | Automotive, AEC-Q100, 74AHC |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Logic Type | Inverter |
|---|
| Number of Circuits | 6 |
|---|
| Number of Inputs | 6 |
|---|
| Features | - |
|---|
| Voltage - Supply | 2 V ~ 5.5 V |
|---|
| Current - Quiescent (Max) | 2μA |
|---|
| Current - Output High, Low | 8mA, 8mA |
|---|
| Logic Level - Low | 0.5 V ~ 1.65 V |
|---|
| Logic Level - High | 1.5 V ~ 3.85 V |
|---|
| Max Propagation Delay @ V, Max CL | 7.5ns @ 5V, 50pF |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Supplier Device Package | 14-TSSOP |
|---|
| Package / Case | 14-TSSOP (0.173", 4.40mm Width) |
|---|
We can supply NXP Semiconductors part# 74AHC04PW-Q100J. Use the request quote form to request 74AHC04PW-Q100J pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 74AHC04PW-Q100J. The price and lead time for 74AHC04PW-Q100J depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 74AHC04PW-Q100J. We look forward to doing business with you.
