Technical Specifications of SN74AS804BDWG4
| Datasheet |  SN74AS804BDWG4 datasheet |
|---|
| Category | Integrated Circuits (ICs) |
|---|
| Family | Logic - Gates and Inverters |
|---|
| Manufacturer | Texas Instruments |
|---|
| Series | 74AS |
|---|
| Packaging | Tube |
|---|
| Part Status | Active |
|---|
| Logic Type | NAND Gate |
|---|
| Number of Circuits | 6 |
|---|
| Number of Inputs | 2 |
|---|
| Features | - |
|---|
| Voltage - Supply | 4.5 V ~ 5.5 V |
|---|
| Current - Quiescent (Max) | - |
|---|
| Current - Output High, Low | 48mA, 48mA |
|---|
| Logic Level - Low | 0.8V |
|---|
| Logic Level - High | 2V |
|---|
| Max Propagation Delay @ V, Max CL | 4ns @ 5V, 50pF |
|---|
| Operating Temperature | 0°C ~ 70°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Supplier Device Package | 20-SOIC |
|---|
| Package / Case | 20-SOIC (0.295", 7.50mm Width) |
|---|
We can supply Texas Instruments part# SN74AS804BDWG4. Use the request quote form to request SN74AS804BDWG4 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SN74AS804BDWG4. The price and lead time for SN74AS804BDWG4 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SN74AS804BDWG4. We look forward to doing business with you.
