Technical Specifications of 74F02SJ
| Category | Integrated Circuits (ICs) |
|---|
| Family | Logic - Gates and Inverters |
|---|
| Manufacturer | Fairchild Semiconductor |
|---|
| Series | 74F |
|---|
| Packaging | Tube |
|---|
| Part Status | Obsolete |
|---|
| Logic Type | NOR Gate |
|---|
| Number of Circuits | 4 |
|---|
| Number of Inputs | 2 |
|---|
| Features | - |
|---|
| Voltage - Supply | 4.5 V ~ 5.5 V |
|---|
| Current - Quiescent (Max) | - |
|---|
| Current - Output High, Low | 1mA, 20mA |
|---|
| Logic Level - Low | 0.8V |
|---|
| Logic Level - High | 2V |
|---|
| Max Propagation Delay @ V, Max CL | 5.5ns @ 5V, 50pF |
|---|
| Operating Temperature | 0°C ~ 70°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Supplier Device Package | 14-SOP |
|---|
| Package / Case | 14-SOIC (0.209", 5.30mm Width) |
|---|
We can supply Fairchild Semiconductor part# 74F02SJ. Use the request quote form to request 74F02SJ pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 74F02SJ. The price and lead time for 74F02SJ depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 74F02SJ. We look forward to doing business with you.
