74LVQ138SJX
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 74LVQ138SJX |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Description | Decoder/Demultiplexer 1 x 3:8 16-SOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 74LVQ138SJX Price |  |
Technical Specifications of 74LVQ138SJX
| Category | Integrated Circuits (ICs) |
|---|---|
| Family | Logic - Signal Switches, Multiplexers, Decoders |
| Manufacturer | Fairchild Semiconductor |
| Series | 74LVQ |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Type | Decoder/Demultiplexer |
| Circuit | 1 x 3:8 |
| Independent Circuits | 1 |
| Current - Output High, Low | 12mA, 12mA |
| Voltage Supply Source | Single Supply |
| Voltage - Supply | 2 V ~ 3.6 V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.209", 5.30mm Width) |
| Supplier Device Package | 16-SOP |
