STR-W6750F
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | STR-W6750F |
|---|---|
| Manufacturer | Sanken |
| Description | Converter Offline Flyback Topology 19kHz ~ 25kHz TO-220F-6L |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| STR-W6750F Price |  |
Technical Specifications of STR-W6750F
| Datasheet |  STR-W6750F datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | PMIC - AC DC Converters, Offline Switchers |
| Manufacturer | Sanken |
| Series | STR-W6700 |
| Packaging | Bulk |
| Part Status | Active |
| Output Isolation | Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 650V |
| Topology | Flyback |
| Voltage - Start Up | 18.2V |
| Voltage - Supply (Vcc/Vdd) | 9.7 V ~ 35 V |
| Duty Cycle | - |
| Frequency - Switching | 19kHz ~ 25kHz |
| Power (Watts) | - |
| Fault Protection | Current Limiting, Over Load, Over Voltage |
| Control Features | Soft Start |
| Operating Temperature | -20°C ~ 115°C (TA) |
| Package / Case | TO-220-7 Full Pack (6 Leads) |
| Supplier Device Package | TO-220F-6L |
| Mounting Type | Through Hole |
