NCV7751DQR2G
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | NCV7751DQR2G |
|---|---|
| Manufacturer | ON Semiconductor |
| Description | IC DVR LO SIDE 12CH RELAY 24SSOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| NCV7751DQR2G Price |  |
Technical Specifications of NCV7751DQR2G
| Datasheet |  NCV7751DQR2G datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | PMIC - Power Distribution Switches, Load Drivers |
| Manufacturer | ON Semiconductor |
| Series | Automotive, AEC-Q100 |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Switch Type | Relay, Solenoid Driver |
| Number of Outputs | 12 |
| Ratio - Input:Output | 1:12 |
| Output Configuration | Low Side |
| Output Type | N-Channel |
| Interface | SPI |
| Voltage - Load | 36V (Max) |
| Voltage - Supply (Vcc/Vdd) | 3 V ~ 5.5 V |
| Current - Output (Max) | 600mA |
| Rds On (Typ) | 1.3 Ohm |
| Input Type | - |
| Features | - |
| Fault Protection | Open Load Detect, Over Temperature |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Package / Case | 24-SSOP (0.154", 3.90mm Width) |
| Supplier Device Package | 24-SSOP |
