TDE1898CFP
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TDE1898CFP |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | IC IPS HISIDE DRVR 0.5A 20-SOIC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| TDE1898CFP Price |  |
Technical Specifications of TDE1898CFP
| Datasheet |  TDE1898CFP datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | PMIC - Power Distribution Switches, Load Drivers |
| Manufacturer | STMicroelectronics |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Switch Type | General Purpose |
| Number of Outputs | 1 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | On/Off |
| Voltage - Load | 18 V ~ 35 V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 500mA |
| Rds On (Typ) | - |
| Input Type | Differential |
| Features | - |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, UVLO |
| Operating Temperature | -25°C ~ 85°C (TA) |
| Package / Case | 20-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 20-SO |
