UC37133DG4
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | UC37133DG4 |
|---|---|
| Manufacturer | Texas Instruments |
| Description | IC HIGH SIDE PWR-SW 8-SOIC |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| UC37133DG4 Price |  |
Technical Specifications of UC37133DG4
| Datasheet |  UC37133DG4 datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | PMIC - Power Distribution Switches, Load Drivers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| Part Status | Active |
| Switch Type | General Purpose |
| Number of Outputs | 1 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | Bipolar |
| Interface | On/Off |
| Voltage - Load | 8 V ~ 65 V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 300mA |
| Rds On (Typ) | - |
| Input Type | Non-Inverting |
| Features | - |
| Fault Protection | - |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
