MC10XS4200FK
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MC10XS4200FK |
|---|---|
| Manufacturer | Freescale Semiconductor - NXP |
| Description | IC SW HIGH SIDE 24V DUAL 23PQFN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MC10XS4200FK Price |  |
Technical Specifications of MC10XS4200FK
| Datasheet |  MC10XS4200FK datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | PMIC - Power Distribution Switches, Load Drivers |
| Manufacturer | Freescale Semiconductor - NXP |
| Series | - |
| Packaging | Tray |
| Part Status | Active |
| Switch Type | General Purpose |
| Number of Outputs | 2 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | SPI |
| Voltage - Load | 8 V ~ 36 V |
| Voltage - Supply (Vcc/Vdd) | 3 V ~ 5.5 V |
| Current - Output (Max) | 6A |
| Rds On (Typ) | 10 mOhm (Max) |
| Input Type | - |
| Features | Internal PWM, Slew Rate Controlled, Watchdog Timer |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, UVLO |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Package / Case | 23-PowerQFN |
| Supplier Device Package | 23-PQFN (12x12) |
