TPS22967DSGR
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TPS22967DSGR |
|---|---|
| Manufacturer | Texas Instruments |
| Description | IC LOAD SWITCH 4A 8WSON |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| TPS22967DSGR Price |  |
Technical Specifications of TPS22967DSGR
| Datasheet |  TPS22967DSGR datasheet |
|---|---|
| Category | Integrated Circuits (ICs) |
| Family | PMIC - Power Distribution Switches, Load Drivers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Switch Type | General Purpose |
| Number of Outputs | 1 |
| Ratio - Input:Output | 1:1 |
| Output Configuration | High Side |
| Output Type | N-Channel |
| Interface | On/Off |
| Voltage - Load | 2.5 V ~ 5.5 V |
| Voltage - Supply (Vcc/Vdd) | 0.8 V ~ 5.5 V |
| Current - Output (Max) | 4A |
| Rds On (Typ) | 22 mOhm |
| Input Type | Non-Inverting |
| Features | Load Discharge, Slew Rate Controlled |
| Fault Protection | - |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Package / Case | 8-WFDFN Exposed Pad |
| Supplier Device Package | 8-WSON (2x2) |
