HSHM-S055B1-5AP1-TR40B
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | HSHM-S055B1-5AP1-TR40B |
|---|---|
| Manufacturer | 3M |
| Description | CONN SOCKET HSHM 55 POS TH RA |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| HSHM-S055B1-5AP1-TR40B Price |  |
Technical Specifications of HSHM-S055B1-5AP1-TR40B
| Product Photos | HSHM-S055B1-5AP1-TR40B |
|---|---|
| PCN Obsolescence/ EOL | TR40B Plating 30/Jul/2010 |
| PCN Design/Specification | HSHM, UHM Voltage 15/Oct/2014 |
| Standard Package | 100 |
| Category | Connectors, Interconnects |
| Family | Backplane Connectors - Hard Metric, Standard |
| Series | MetPak? HSHM |
| Packaging | Bulk |
| Connector Type | Receptacle, Female Sockets |
| Connector Style | B 11 |
| Number of Positions | 55 |
| Number of Positions Loaded | All |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 5 |
| Mounting Type | Through Hole, Right Angle |
| Termination | Press-Fit |
| Connector Usage | Backplane |
| Contact Finish | Gold |
| Contact Finish Thickness | 50μin (1.27μm) |
| Current Rating | 1A |
| Voltage Rating | - |
| Operating Temperature | -55°C ~ 125°C |
| Features | Shielded |
| Other Names | 0-00-51111-53767-1 5111153767 51111537671 80400015519 HSHMS055B15AP1TR40B |
