NUS2401SNT1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | NUS2401SNT1 |
|---|---|
| Manufacturer | ON Semiconductor |
| Description | TRANS 2NPN/1PNP PREBIAS SC74 |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| NUS2401SNT1 Price |  |
Technical Specifications of NUS2401SNT1
| Datasheet |  NUS2401SNT1 datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - Bipolar (BJT) - Arrays, Pre-Biased |
| Manufacturer | ON Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Transistor Type | 2 NPN, 1 PNP - Pre-Biased |
| Current - Collector (Ic) (Max) | 200mA |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
| Resistor - Base (R1) (Ohms) | 175, 10k |
| Resistor - Emitter Base (R2) (Ohms) | 10k |
| DC Current Gain (hFE) (Min) @ Ic, Vce | - |
| Vce Saturation (Max) @ Ib, Ic | 250mV @ 1mA, 10mA / 250mV @ 300μA, 10mA |
| Current - Collector Cutoff (Max) | 500nA |
| Frequency - Transition | - |
| Power - Max | 350mW |
| Mounting Type | Surface Mount |
| Package / Case | SC-74, SOT-457 |
| Supplier Device Package | SC-74 |
